32
Table 2 - Utility Menu Options and Settings
The 6 menu options allow users to control or check the following options:
DCR trigger delay function: (dCdLy: DCR delay)
Control beep sound: (bEEP: beep sound)
Set auto power-off: (AoFF: auto power off)
Set power-up state: (PuP: power-up state)
Reset to default settings: (dEF: default settings)
Indicate battery voltage: (bAtt: battery voltage)
By default, the first option after entering the utility menu is “dCdLy”. The primary display
indicates the menu option, and the secondary display indicates the current settings or
parameters configured for the selected option. To change the settings or parameters, use the
and arrow keys. To change or select a different menu option, press the
button once. For each button press, the meter will traverse through each menu options
and will repeat itself in the following order:
dCdly bEEP AoFF PuP dEF bAtt
Note: The settings and parameters are temporarily “remembered” once the button is
pressed to select a different menu option. To save all settings permanently, exit the menu using
the save and exit method. With the exception of “bEEP” and “AoFF” settings, in which case
under these settings, changes are temporarily saved even when exiting the menu without
saving. (See “Exit Utility Menu” section for details).
DCR Trigger delay Setup (dCdLy)
The “dCdLy” menu option is used to set the trigger delay time ranging from 0000 to 9999ms.
