34
No timer. Manual
power off only
Table 3 - Auto Power-Off Options
Default Setting: 5 mins
When the auto power-off option is set to any of the configured settings in Table 3 above (Error!
Reference source not found.except for “OFF”), upon exiting the utility menu the LCD display
will have a “@OFF” indicator. This means a timer has been set for auto power-off. To set the
auto power-off select the desired minutes and press the button for 2 seconds.
Note: When an external 12VDC AC adapter is used to power the instrument, the auto power-off
feature will automatically be disabled. This is indicated on the LCD display when the “@OFF”
indicator disappears. Under this condition, the meter will remain powered ON continuously. In
this state, powering off the instrument would require manually pushing and holding down the
button for 2 seconds.
When external power is removed, the meter will automatically re-enable auto power-off again
and “@OFF” indicator will re-appear if a time has been set from the “AoFF” option of the utility
menu.
Power-up State (PuP)
The “PuP” menu option allows user to configure the power-up state of the LCR meter, allowing
user to restore settings saved into internal EEPROM memory at power-up.
In the utility menu, when the primary display shows “PuP”, there are two settings selectable
and shown on the secondary display. “PrE” and “SEt”.
Default Setting: PrE
Storable Settings
Primary function mode (i.e. L/C/R)
Secondary function mode (i.e. D/Q)
Test frequency
Measurement rate
