BK Precision 9104 - 2.2 Rear Panel

2.2 Rear Panel
Figure 3 - Rear Panel
⑧ Remote Sense
Shorting the remote sensing terminal or connecting the sense terminals
with reversed polarity will damage the power supply.
⑨ Thermostatically controlled cooling Fan
⑩ Analog Remote Control Terminal
⑪ USB Port
⑫ AC Input Socket with Fuse Compartment
8
9
12
11
10
