54
We recommend that you retain the original carton and packing materials in
case it ever becomes necessary to return your robot for service. You can only
return the robot in the original carton and packing materials otherwise the
warranty will expire. This is the only way to safely protect the robot against
damage in transit. If you do dispose of the carton and the packing materials,
please remember to recycle with due care to the environment.
5.2 Mounting the brushes
Place the side brushes as shown in Figure 8.
The side brushes are indicated with “L” and “R”. Make sure the L/R mark on
the side brush matches the L/R mark on the base of the robot.
Figure 8 - Mounting the brushes
5.3 Installing the suitable cleaning kit
Depending on your cleaning purpose, you need to install the most
appropriate cleaning kit. Table 10 shows an overview.
Cleaning purpose Floor type (examples) Cleaning kits
dry cleaning carpets (< 2 cm) normal suction nozzle
dry cleaning laminate ooring brush suction nozzle
wet cleaning laminate ooring and tiles oors mopping kit
Table 10 - Select the suitable cleaning kit
The following sections explain how to install the dierent cleaning kits.
