3.8.5 CT-current transformer interface
Table 3-8
PIN Define Function Remark
For Connecting to
current transformer
of grid R phase
2
Negative pole of current
transformer Output
CT-R-(Black)
1
Positive pole of current
transformer Output
CT-R+(Red)
Figure 3-9 COM interface
DRMs cables
Tighten the screw
Connector housing
Signal extension cable
N
L
