JUST POWER ON74
2.4.3 Installation Angle Requirements
The system is equipped with a base, the base is placed on a flat ground, and the
system is installed by stacking in layers.
The system should be installed close to the wall, and both sides of each layer of
equipment need to be fixed on the wall through brackets.
The system is installed perpendicular to the horizontal floor.
2.4.4 Space requirements for single system installation
The following diagram shows the EP600 system installed in a single group.
Picture 2-1
Figure 2-2 Ground，Base, Wall
OK
NO
90°
NO NO
NO
OK
max5°
Ground
Wall
B500
Base
B500
EP600
