Bluetti EP600 - Page 78

JUST POWER ON 75
636mm
(25.04in)
119mm
(4.685in)
320mm
(12.6in)
2.4.5 Space requirements for multiple systems are installed side by side
When multiple systems are installed side by side, keep at least 1000mm distance
between them to reduce the impact of heat dissipation.
2.4.7 Installation
location requirements
2.4.6 Size of base bracket installation
Table 2-3 ground
Figure 2-4
3D
Ground
≥1000mm
≥300mm ≥300mm
≥300mm
≥300mm
