BMC H-80 Series User Manual

H-80 Series User Manual V1.0
13 / 46
CAUTIONS!
• The air filter must be in place when the device is operating. The filter cover can protect the
device from liquid being sprinkled on the device by accident.
• Installing the air filter and filter cap, device must be unplugged.
11.3 Connecting to Power
(1) Insert the plug of the power cord into the DC inlet on the back of the device, as shown in
Fig. 11-3;
(2) Press the power cord locker, and fix the power cord and power connector. The function of
the locker is to prevent the power cord falling off from the power port, as shown in Fig. 11-4;
(3) Insert the power cord plug into the power supply socket.
Power Cord
DC Inlet
Fig. 11-3
Power Cord Locker
Fig. 11-4
Note: The length of the power cord is 1.8m without the function of preventing
electromagnetic interference.
