BMC H-80 Series User Manual

H-80 Series User Manual V1.0
26 / 46
(2) Returning to the Main Interface
Turn the Knob to make the cursor stay on ―Home page‖, and then press the Knob
to exit the Setup Interface. The screen will display the Main Interface shown in Fig.
13-13.
13.1.13 Accessing the Trend Chart Interface
When the cursor is on the icon , the screen displays the Trend Chart Interface. Access the
interface by pressing the Knob , as shown in Fig. 13-14. The flow, temp, FiO
2
, RR of the
first day, the third day and the seventh day can be selected from the interface for reviewing.
Turn the the Knob to select the data of the first day, the third day and the seventh day
for reviewing.
Fig. 13-14
When the page as shown in the Fig. 13-14 is displayed on the display screen, press the
Knob and the data reviewing will be adjustable, as shown in the Fig. 13-15, and turning
the Knob to switch among the flow, temp, FiO
2
and RR.
Fig. 13-15
