H-80 Series User Manual V1.0
18 / 46
WARNINGS!
Prevent the body skin from directly contacting with the breathing tube for a long time.
Do not make any changes to the breathing tube and nasal cannula.
Please check whether the breathing tube is damaged or has foreign matter before using, if
any, please clean or replace the breathing tube.
Do not place the breathing tube and nasal cannula in any environment which prevents
them from heat dissipation or being directly heated, for example, packaged in the quilt, or
placed in the heat insulation rescue table or incubator of the newborn, or beside the air
outlet of heater for heating or air conditioner of hot air mode, which may cause extremely
serious injury.
CAUTION!
Please keep the breathing tube in work away from EEG, EKG/ECG, EMG and other
electronic lead wires to reduce the signal interference.
11.8 Connecting the
oxygen
For H-80M model: please first connect the output end of the medical gas low pressure hose
with the flow meter, then connect the flow meter with the oxygen tube, and connect the
oxygen tube to the oxygen inlet of the device, finally connect the input end of the medical
gas low pressure hose to the oxygen source, as shown in Fig. 11-12.
Medical Gas Low Pressure Hose
Oxygen Inlet
Flow Meter
Oxygen Tube
Fig. 11-12
For H-80A and H-80AS models: connect the output end of the medical gas low pressure hose
to the oxygen inlet of the device and ensure the medical gas low pressure hose to be firmly
connected with the connector, then connect the input end of the medical gas low pressure
hose to the oxygen source, as shown in Fig. 11-13.
