Lock the lock with the ignition
key.
Removing rear seat
with Passenger Bundle
OE
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Open seat lock 1 with the igni-
tion key.
Lift the rear seat at the rear
and then work it back and up
to remove.
Remove the ignition key from
the lock and place the rear
seat, upholstered side down,
on a clean surface.
Installing rear seat
with Passenger Bundle
OE
Engage the rear seat in
mounts 2 on left and right.
Swing the rear seat down,
pushing it lightly forward.
Lock the seat lock with the ig-
nition key.
4
56
z
Operation
