Replace the faulty number-
plate light.
Bulb for number-plate
light
W5W / 12 V / 5 W
Use a clean, dry cloth to hold
the bulb in order to keep the
glass free of dirt and foreign
matter.
Push the bulb into the bulb
socket.
Press number-plate light bulb 1
into the light housing.
Fuses
Removing fuse
Any attempt to jumper a
defective fuse gives rise to
the risk of a short-circuit and fire.
Always replace a defective fuse
with a new fuse of the same
amperage.
Switch off the ignition.
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Removing rear seat cover
( 55).
with Passenger Bundle
OE
Removing rear seat ( 56).
Squeeze the latches together
and remove cover of fuse
box 1.
To replace the main fuse, re-
move cover 2 of the relay box.
Use the tool from the on-board
toolkit to pull the defective fuse
up and out of the fuse box.
If fuse defects recur fre-
quently have the electric
circuits checked by a specialist
9
158
z
Maintenance
