BMW HP4 - Underneath the Seat

Underneath the seat
1 Rear seat cover ( 55)
with Passenger
Bundle
OE
Rear seat ( 56)
2 Helmet holder ( 57)
3 with Passenger
Bundle
OE
Luggage loops ( 58)
4 Toolkit (behind side panel)
( 130)
with Passenger
Bundle
OE
Parts of the toolkit are loc-
ated under the rear seat
5 Fuse box ( 158)
6 Rider's Manual
7 Battery ( 160)
with anti-theft alarm
(DWA)
OE
different battery position:
turned 180°.
2
16
z General views
