Removing and installing
mirrors
Removing mirror
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
On each side, remove nuts 1
and remove the mirrors.
Secure fairing 2 to fairing
bracket 3 on left and right.
If cable ties are used, affix
adhesive tape as protection at
the points where chafing might
occur.
Use the HP Race Cover
Kit from BMW Motorrad to
cover the screw holes and re-
store the secure fastening of the
mount.
Installing mirrors
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Remove the fairing-panel
fasteners.
Engage the left and right mir-
rors in mounts 4.
Install the nuts at the rear of
the fairing panel and tighten to
specified torque.
Mirror to front panel car-
rier
Thread-locking compound:
mechanical
8 Nm
6
106
z
On the race track
