Step 4 Attach one Rail Support (Y9) to the Y Frame Assembly with
three M4 x 16 Machine Screws and Nuts as shown.
Step 5 Attach the second Rail Support (Y9) to the Y Frame Assembly
with three M4 x 16 Machine Screws and Nuts as shown.
