The output of the first PT1 element is linked to the input of the second PT1 element
which includes the thermal motor time constant. This output may be permanently
100%. This corresponds to the complete thermal capacity of the motor.
If 102% is
reached, the drive switches off with an error message. Both outputs are connected to
the adjustable alarm limit.
Operation Mode 571
Function
42 -
I²t, Single-Motor,
Error Switch Off
The I²t capacity of the motor is monitored with rated
values from the active dataset.
If the fixed threshold values exceed 100%
motor
(120%
stator
), the drive switches off with fault “F0401”
in the active dataset.
51 -
I²t, Multi-Motor Opera-
tion, Warning
The I²t capacity of the motors regarding their related
ratings is monitored in each of the four data sets. If
the
Warning Limit Motor I
2
t 615 is reached, the
warning message "A0200" is signaled from the active
data set.
52 -
I²t, Single-Motor,
Warning
The I²t capacity of the motor is monitored with rated
values from the active dataset.
If the Warning Limit Motor I
2
t 615 is reached, the
warning message "A0200" is signaled from the active
data set.
61 -
I²t, Multi-Motor Opera-
tion,
Warning and Error
Switch Off
The I²t capacity of the motors regarding their related
ratings is monitored in each of the four data sets. If
the Warning Limit Motor I
2
t 615
is reached, the
warn
ing message "A0200" is signaled from the active
data set. If the fixed threshold values exceed
100%
motor
(120%
stator
), the
drive switches off with fault
“F0401”
in the active dataset. Both incidences are
triggered from the active dataset.
62 -
I²t, Single-Motor,
Warning and Error
Switch Off
The I²t capacity of the motor is monitored with rated
values from the active dataset.
If the Warning Limit Motor I
2
t 615
is reached, the
warning message "A0200" is signaled from the active
data set. If the fixed threshold values exceed
100%
motor
(120%
stator
), the drive switches off wi
th fault
“F0401”
in the active dataset. Both incidences are
triggered from the active dataset.
The thermal time constant of the motor is in the range from few minutes to a couple
of hours. This motor-specific parameter is set via T hermal time constant motor 608.
Substantially smaller is the thermal stator time constant. To protect the stator wind-
ing additional monitoring is required which is determined by
Thermal time constant
stator
609.
These values can be taken from the corresponding motor data sheets. When estimat-
ed time constants are used because the required data are not available then an opti-
mal thermal motor protection cannot be guaranteed.
