Percentage ramp
No.
Description
Unit
Setting range
Chapter
477
Gradient percentage ramp
%/s
0 ... 60000
14.8
Technology Controller
478 Actual percentage source - Selection
17.3
Positioning
479
time constant positioning contr.
ms
1.00 ... 9999.99
12.6.2
Fixed Frequencies
480
Fixed frequency 1
Hz
-999.99 ... 999.99
14.6.1
481
Fixed frequency 2
Hz
-999.99 ... 999.99
14.6.1
482
Fixed frequency 3
Hz
-999.99 ... 999.99
14.6.1
483
Fixed frequency 4
Hz
-999.99 ... 999.99
14.6.1
489
JOG frequency
Hz
-999.99 ... 999.99
14.6.2
Speed Sensor 1
490
Operation mode
-
Selection
10.4.1
491
Division Marks
-
1 ... 8192
10.4.2
PWM-/repetition frequency input
496
Operation mode
-
Selection
14.11
497
Divider
-
1 ... 8192
14.11
Brake Chopper
506 Trigger threshold V
225 ... 1000.0 (201)
425 ... 1000.0 (401)
18.4
Motor Chopper
507
Trigger threshold V
225 ... 1000.0 (201)
425 ... 1000.0 (401)
18.7.1
Digital Outputs
510
Setting Frequency
Hz
0.00 ... 999.99
15.3.2
Speed Sensor 1
511
EC1 Gear Factor Numerator
-
-300.00 … 300.00
10.4.3
512
EC1 Gear Factor Denominator
-
0.01 … 300.00
10.4.3
Speed controller
515
Integral Time Speedtracking
ms
1 … 60 000
17.5.4.3
Digital Outputs
517
Setting Frequency Off Delta
Hz
0.00 … 999.99
15.3.2
Percentage Value Limits
518
Minimum Reference Percentage
%
0.00 ... 300.00
14.3
519
Maximum Reference Percentage
%
0.00 ... 300.00
14.3
Fixed Percentages
520
Fixed percentage 1
%
-300.00 ... 300.00
14.6.3
521
Fixed percentage 2
%
-300.00 ... 300.00
14.6.3
522
Fixed percentage 3
%
-300.00 ... 300.00
14.6.3
523
Fixed percentage 4
%
-300.00 ... 300.00
14.6.3
Digital Outputs
530
Operation mode digital output 1
-
Selection
15.3
532
Operation mode digital output 3
-
Selection
15.3
535
Op. Mode ext. Error
-
Selection
15.4.12
536
Create Warning Mask
-
Selection
15.3.8
540 Operation mode comparator 1 - Selection
15.5.2
541
Comparator On above
%
-300.00 ... 300.00
15.5.2
06/13 Operating Instructions ACU 281
