BONFIGLIOLI ACTIVE Cube ACU 401-23 User Manual

Motor connection ACU 201 (up to 3.0 kW) and 401 (up to 4.0 kW)
Phoenix ZEC 1,5/ .. ST7,5
0.2 … 1.5 mm
AWG 24 … 16
2
0.2 … 1.5 mm
AWG 24 … 16
2
0.25 … 1.5 mm
AWG 22 … 16
2
0.25 … 1.5 mm
AWG 22 … 16
2
X2
Star connection
V W
U
Delta connection
V W
U
V WU
Rb2Rb1
M
3~
Connection of brake resistor with temperature switch
X2
V W
U Rb2Rb1
R
b
T1
Rb1 Rb2
T2
X2
Phoenix ZEC 1,5/ .. ST7,5
0.2 … 1.5 mm
AWG 24 … 16
2
0.2 … 1.5 mm
AWG 24 … 16
2
0.25 … 1.5 mm
AWG 22 … 16
2
0.25 … 1.5 mm
AWG 22 … 16
2
06/13 Operating Instructions ACU 61
