5.11.5.2 Source numbers of the RxPDO’s for received data
Equivalent to the input links of the TxPDO’s, the received data of the RxPDO’s are
displayed via sources or source numbers. The sources existing in this way can be
used in the frequency inverter via the local input links for the data targets.
RxPDO1
Byte
Source No.
Boolean
value
RxPDO1
Byte
Source No.
uint/int
value
RxPDO1
Byte
Source No.
long-
Value
0 0 0
1
700
Boolean1
1
704
Word1
1
2 2 2
3
701
Boolean2
3
705
Word2
3
708
Long1
4 4 4
5
702
Boolean3
5
706
Word3
5
6 6 6
7
703
Boolean4
7
707
Word4
7
709
Long2
RxPDO2
Byte
Source No.
Boolean
value
RxPDO2
Byte
Source No.
uint/int
value
RxPDO2
Byte
Source No.
long
value
0 0 0
1
710
Boolean1
1
714
Word1
1
2 2 2
3
711
Boolean2
3
715
Word2
3
718
Long1
4 4 4
5
712
Boolean3
5
716
Word3
5
6 6 6
7
713
Boolean4
7
717
Word4
7
719
Long2
RxPDO3
Byte
Source No.
Boolean
value
RxPDO3
Byte
Source No.
uint/int
value
RxPDO3
Byte
Source No.
long
value
0 0 0
1
720
Boolean1
1
724
Word1
1
2 2 2
3
721
Boolean2
3
725
Word2
3
728
Long1
4 4 4
5
722
Boolean3
5
726
Word3
5
6 6 6
7
723
Boolean4
7
727
Word4
7
729
Long2
With this method, there are up to three possibilities for a meaning of the contents of
the individual bytes. Each byte may only be used for one possibility.
Note: Depending on the selected data information the percentages values are
displayed via the uint/int inputs.
