EM-RES-03 5910/07
6.1.7 Adjustment
As a result of component tolerances, it can be necessary to ad
ust the analo
input.
Parameter
Adjustment 568 is used for this purpose.
Operation mode Function
0 - no adjustment Normal operation
1 - Adjustment 0 V / 0 mA
Adjustment of the measurement with an analog
signal of 0 V or 0 mA.
2 - Adjustment 10 V / 20 mA
Adjustment of the measurement with an analog
signal of 10 V or 20 mA.
Example of the adjustment of the analog input with a voltage signal:
Note: The measurements for the adjustment are to be done with a suitable
measuring instrument and the correct polarity.
If not, faulty measurements can result.
• Apply 0 V to the analo
input; e.
. with a wired link from the socket of the analo
input X410A.6 to socket X210B.7 (earth/GND) of the frequency inverter.
• Select operation mode "1 - Adjustment 0 V / 0 mA“.
• Apply 10 V to the analog input, e.g. with a wired link from the socket of the analo
input to socket X210B.5 (reference output 10 V) of the frequency inverter.
• Select operation mode "2 - Adjustment 10 V / 20 mA“.
6.1.8 Filter time constant
The time constant of the filter for the reference analog value can be set via the pa-
rameter
Filter time constant 561.
The time constant states the time for which the input signal is averaged by means of a
low pass filter, e.g. in order to eliminate fault effects.
The setting range is a range of values between 0 ms and 5000 ms in 15 steps.
Operation mode Function
0 - Time constant 0 ms
Filter deactivated – analog reference value is for-
warded unfiltered
2 - Time constant 2 ms
4 - Time constant 4 ms
8 - Time constant 8 ms
16 - Time constant 16 ms
32 - Time constant 32 ms
64 - Time constant 64 ms
128 - Time constant 128 ms
256 - Time constant 256 ms
512 - Time constant 512 ms
1000 - Time constant 1000 ms
2000 - Time constant 2000 ms
3000 - Time constant 3000 ms
4000 - Time constant 4000 ms
5000 - Time constant 5000 ms
Filter activated – averaging of the input signal via
the set value of the filter time constants
