EM-RES-03 6110/07
6.3 Digital inputs EM-SxIND
The EM-RES-03 expansion module has three digital inputs. The assignment of the
control signals to the available software functions can be adapted to the application in
question. As a function of the selected
Configuration 30, the factory-set assignment
and the selection of the operation mode differ. In addition to the di
gital control inputs
available, further internal logistic signals are also available as sources.
The individual software functions are assi
gned to the various signal sources via
parameterization-capable inputs. This enables a flexible and varied use of the digital
control signals.
Operation mode Function
320 - EM-S1IND Signal on digital input 1 (X410B.2)
321 - EM-S2IND Signal on digital input 2 (X410B.3)
322 - EM-S3IND Signal on digital input 3 (X410B.4)
520 - EM-S1IND inverted Inverted signal on digital input 1 (X410B.2)
521 - EM-S2IND inverted Inverted signal on digital input 2 (X410B.3)
522 - EM-S3IND inverted Inverted signal on digital input 3 (X410B.4)
Alongside the operation modes listed, those stated in the operating instructions of the
frequency inverter in the chapter "Digital inputs" also apply.
