EM-RES-03 10/0768
7 Parameter list
The parameter list is structured according to the menu branches of the control unit.
For better clarity, the parameters are marked with pictograms:
The parameter is available in the four data sets
The parameter value is adjusted by the SETUP routine if a control method for a
synchronous machine is selected for parameter C
onfiguration 30.
This parameter cannot be written in the operation of the frequency inverter
7.1 Actual value menu (VAL)
Actual values of the machine
No. Description Unit Display range Chapter
219 Frequency speed sensor 2 Hz 0.0 ... 999.99 6.6
220 Speed, speed sensor 2 rpm 0 ... 60000 6.6
Actual values of the frequency inverter
253 Analog input EM-S1INA V -10 ... +10 6.6
7.2 Parameter menu (PARA)
Resolver
No. Description Unit Setting range Chapter
381 No. of pole pairs - 1 ... 7 6.4
382 Offset ° -360.0 ... 360.0 6.4.1
492 Evaluation Mode - Selection 6.4.3
Digital outputs
533 Op. Mode EM-S1OUTD - Selection 6.2.2
534 Op. Mode EM-S2OUTD - Selection 6.2.2
Analog input
560 Tolerance band % 0.00 ... 25.00 6.1.5
561 Filter time constant - Selection 6.1.8
562 Operation mode - Selection 6.1.3
563 Error/warning behavior - Selection 6.1.6
564 Characteristic point X1 % -100.00 ... 100.00 6.1.2
565 Characteristic point Y1 % -100.00 ... 100.00 6.1.2
566 Characteristic point X2 % -100.00 ... 100.00 6.1.2
567 Characteristic point Y2 % -100.00 ... 100.00 6.1.2
568 Adjustment - Selection 6.1.7
Speed controller
766 Actual speed source - Selection 6.4.2
System bus
900 Node-ID - -1 ... 63 5.5
903 Baud-Rate - Selection 5.4
904 Boot-Up Delay ms 3500 ... 50000 5.8.4
918 SYNC-Identifier - 0 ... 2047 5.8.2
919 SYNC-Time ms 0 ... 50000 5.9.2
921 RxSDO1-Identifier - 0 ... 2047 5.9.4
922 TxSDO1-Identifier - 0 ... 2047 5.9.4
10/07 EM-RES-03 69
System bus
No. Description Unit Display range Chapter
923 SDO2 Set Active - Selection 5.9.4
924 RxPDO1-Identifier - 0 ... 2047 5.11.1
925 TxPDO1-Identifier - 0 ... 2047 5.11.1
926 RxPDO2-Identifier - 0 ... 2047 5.11.1
927 TxPDO2-Identifier - 0 ... 2047 5.11.1
928 RxPDO3-Identifier - 0 ... 2047 5.11.1
929 TxPDO3-Identifier - 0 ... 2047 5.11.1
930 TxPDO1 Function - Selection 5.11.2
931 TxPDO1 Time ms 0 ... 50000 5.11.2
932 TxPDO2 Function - Selection 5.11.2
933 TxPDO2 Time ms 0 ... 50000 5.11.2
934 TxPDO3 Function - Selection 5.11.2
935 TxPDO3 Time ms 0 ... 50000 5.11.2
936 RxPDO1 Function - Selection 5.11.2
937 RxPDO2 Function - Selection 5.11.2
938 RxPDO3 Function - Selection 5.11.2
939 SYNC Timeout ms 0 ... 60000 5.11.3
941 RxPDO1 Timeout ms 0 ... 60000 5.11.3
942 RxPDO2 Timeout ms 0 ... 60000 5.11.3
945 RxPDO3 Timeout ms 0 ... 60000 5.11.3
946 TxPDO1 Boolean1 - Selection 5.11.5.1
947 TxPDO1 Boolean2 - Selection 5.11.5.1
948 TxPDO1 Boolean3 - Selection 5.11.5.1
949 TxPDO1 Boolean4 - Selection 5.11.5.1
950 TxPDO1 Word1 - Selection 5.11.5.1
951 TxPDO1 Word2 - Selection 5.11.5.1
952 TxPDO1 Word3 - Selection 5.11.5.1
953 TxPDO1 Word4 - Selection 5.11.5.1
954 TxPDO1 Long1 - Selection 5.11.5.1
955 TxPDO1 Long2 - Selection 5.11.5.1
956 TxPDO2 Boolean1 - Selection 5.11.5.1
957 TxPDO2 Boolean2 - Selection 5.11.5.1
958 TxPDO2 Boolean3 - Selection 5.11.5.1
959 TxPDO2 Boolean4 - Selection 5.11.5.1
960 TxPDO2 Word1 - Selection 5.11.5.1
961 TxPDO2 Word2 - Selection 5.11.5.1
962 TxPDO2 Word3 - Selection 5.11.5.1
963 TxPDO2 Word4 - Selection 5.11.5.1
964 TxPDO2 Long1 - Selection 5.11.5.1
965 TxPDO2 Long2 - Selection 5.11.5.1
966 TxPDO3 Boolean1 - Selection 5.11.5.1
967 TxPDO3 Boolean2 - Selection 5.11.5.1
968 TxPDO3 Boolean3 - Selection 5.11.5.1
969 TxPDO3 Boolean4 - Selection 5.11.5.1
972 TxPDO3 Word1 - Selection 5.11.5.1
973 TxPDO3 Word2 - Selection 5.11.5.1
974 TxPDO3 Word3 - Selection 5.11.5.1
975 TxPDO3 Word4 - Selection 5.11.5.1
976 TxPDO3 Long1 - Selection 5.11.5.1
977 TxPDO3 Long2 - Selection 5.11.5.1
989 Emergency Reaction - Selection 5.8.3
