6.2 Digital outputs EM-S1OUTD and EM-S2OUTD
6.2.1 General
Parameterization of this digital output permits a linking to a variety of functions. The
selection of functions depends on the parameterized configuration.
6.2.2 Operation modes
The operation mode of the digital output EM-S1OUTD (terminal X410A.3) is selected
via the parameter
Operation Mode EM-S1OUTD 533.
The operation mode of the digital output EM-S2OUTD (terminal X410A.4) is selected
via the parameter
Operation Mode EM-S2OUTD 534.
The operation modes to be selected correspond to the table shown in the operatin
g
instructions of the frequency inverter in the chapter "Digital outputs“.
6.2.3 Fixed reference values and fixed value switch-over
Depending on the Reference Frequency Source 475 selected, fixed frequencies can be
used as reference values. The expansion module extends the functionality described in
the operating instructions of the frequency inverter (parameter
Fixed frequency
change-over 1
66 and Fixed frequency change-over 2 67) by the parameter
F
ixe
d
f
requency change-over 3 131 and the matching parameters Fixed frequency 5 485,
Fixed frequency 6 486, Fixed frequency 7 487, Fixed frequency 8 488.
F
ixed frequency
change-over 1
66
F
ixed frequency
change-over 2
67
F
ixed frequency
change-over 3
131
Fixed frequency 1 480
0 0 0
Fixed frequency 2 481
1 0 0
Fixed frequency 3 482
1 1 0
Fixed frequency 4 483
0 1 0
Fixed frequency 5 485
0 1 1
Fixed frequency 6 486
1 1 1
Fixed frequency 7 487
1 0 1
Fixed frequency 8 488
0 0 1
