EM-RES-03 6910/07
10/07 EM-RES-03 69
System bus
No. Description Unit Display range Chapter
923 SDO2 Set Active - Selection 5.9.4
924 RxPDO1-Identifier - 0 ... 2047 5.11.1
925 TxPDO1-Identifier - 0 ... 2047 5.11.1
926 RxPDO2-Identifier - 0 ... 2047 5.11.1
927 TxPDO2-Identifier - 0 ... 2047 5.11.1
928 RxPDO3-Identifier - 0 ... 2047 5.11.1
929 TxPDO3-Identifier - 0 ... 2047 5.11.1
930 TxPDO1 Function - Selection 5.11.2
931 TxPDO1 Time ms 0 ... 50000 5.11.2
932 TxPDO2 Function - Selection 5.11.2
933 TxPDO2 Time ms 0 ... 50000 5.11.2
934 TxPDO3 Function - Selection 5.11.2
935 TxPDO3 Time ms 0 ... 50000 5.11.2
936 RxPDO1 Function - Selection 5.11.2
937 RxPDO2 Function - Selection 5.11.2
938 RxPDO3 Function - Selection 5.11.2
939 SYNC Timeout ms 0 ... 60000 5.11.3
941 RxPDO1 Timeout ms 0 ... 60000 5.11.3
942 RxPDO2 Timeout ms 0 ... 60000 5.11.3
945 RxPDO3 Timeout ms 0 ... 60000 5.11.3
946 TxPDO1 Boolean1 - Selection 5.11.5.1
947 TxPDO1 Boolean2 - Selection 5.11.5.1
948 TxPDO1 Boolean3 - Selection 5.11.5.1
949 TxPDO1 Boolean4 - Selection 5.11.5.1
950 TxPDO1 Word1 - Selection 5.11.5.1
951 TxPDO1 Word2 - Selection 5.11.5.1
952 TxPDO1 Word3 - Selection 5.11.5.1
953 TxPDO1 Word4 - Selection 5.11.5.1
954 TxPDO1 Long1 - Selection 5.11.5.1
955 TxPDO1 Long2 - Selection 5.11.5.1
956 TxPDO2 Boolean1 - Selection 5.11.5.1
957 TxPDO2 Boolean2 - Selection 5.11.5.1
958 TxPDO2 Boolean3 - Selection 5.11.5.1
959 TxPDO2 Boolean4 - Selection 5.11.5.1
960 TxPDO2 Word1 - Selection 5.11.5.1
961 TxPDO2 Word2 - Selection 5.11.5.1
962 TxPDO2 Word3 - Selection 5.11.5.1
963 TxPDO2 Word4 - Selection 5.11.5.1
964 TxPDO2 Long1 - Selection 5.11.5.1
965 TxPDO2 Long2 - Selection 5.11.5.1
966 TxPDO3 Boolean1 - Selection 5.11.5.1
967 TxPDO3 Boolean2 - Selection 5.11.5.1
968 TxPDO3 Boolean3 - Selection 5.11.5.1
969 TxPDO3 Boolean4 - Selection 5.11.5.1
972 TxPDO3 Word1 - Selection 5.11.5.1
973 TxPDO3 Word2 - Selection 5.11.5.1
974 TxPDO3 Word3 - Selection 5.11.5.1
975 TxPDO3 Word4 - Selection 5.11.5.1
976 TxPDO3 Long1 - Selection 5.11.5.1
977 TxPDO3 Long2 - Selection 5.11.5.1
989 Emergency Reaction - Selection 5.8.3
