2.2. PART NUMBER BREAKDOWN
Figure 2-1: Example of M3645 Part Number Breakdown
Base Model Number
The base model number for all line regen units is M3645.
VOLTAGE RATING
A code letter represents the 3-phase AC line input voltage to the regen module. The
voltage rating must be selected for the system voltage that will be applied. See Table
2-1 for available voltage ratings.
Table 2-1: Voltage Ratings
CURRENT RATING
A 3-digit number represents the maximum continuous DC Current (Amps) the regen
module can regenerate.
The M10, M11, M12 frame sizes are capable of handling a 50% overload above this
current rating for 60 seconds. The M15 frame size is capable of a 25% overload above
this current rating for 60 seconds.
300A IDENTIFIER
This single letter code is omitted except for 300A models.
Both a line reactor module and a line regen module are required for 300A models. A
single letter code is used for 300A model line regens to designate the line reactor and
the line regen.
Table 2-2: 300A Identifier
