bonitron M3645 - Table 2-3: Chassis Styles

User’s Manual
11
CHASSIS STYLE
The chassis style is determined by the current rating, and is represented by an
alphanumeric code as defined in Table 2-2. See Section 6.5 for chassis mounting and
dimensional outlines.
Table 2-3: Chassis Styles
CHASSIS CODE
CURRENT
DESCRIPTION
SIZE (H X W X D)
M10
30A
Open Chassis
20.0” x 10.0” x 10.1”
M11
50A
Open Chassis
22.0” x 11.3” x 10.6”
M12
100A
Open Chassis
24.0” x 12.0” x 12.1”
M15
300A
Open Chassis
26.0” x 13.9” x 11.1”
M15 Reactor
300A
Open Chassis
17.9” x 18.8” x 15.2”
See Section 6.5 for chassis mounting and dimensional outlines.
OPTIONS
Two display options are available.
Table 2-4: Option Codes
OPTION CODE
DESCRIPTION
D
Digital Diagnostic Display
L
Basic LED Indicators
NOTE: The KIT 3645DD external display is only compatible with “L” versions of the
M3645 line regen. Only a single display can be used for each line regen. The line
regen is unable to power more than a single display.
