bonitron M3645 - General Specifications Chart; Table 2-5: General Specifications

M3645
12
2.3. GENERAL SPECIFICATIONS CHART
Table 2-5: General Specifications
PARAMETER
SPECIFICATION
AC Line Voltage
Voltage Rating
50 or 60 Hz
Voltage Min
Voltage Max
L
207 VAC
253 VAC
E
342 VAC
418 VAC
H
414 VAC
506 VAC
C
518 VAC
600 VAC
DC Input Current
 30-300A, continuous
 150% of rating, 60 second overload for M10,
M11, M12 chasses
 125% of rating, 60 second overload for M15
chassis
Control Voltage
 Internal
Indicators
 Power
 Regen
 Fault
 Optional 4 line character display
Inputs
 Enable 24VDC - 5mA
 Fault Recall 24VDC – 5mA
Outputs
 Ready 200VDC - 100 mA
Operating Temp
 0 to +40
O
C
Storage Temp
 -20
O
to +65
O
C
Humidity
 Below 90%, non-condensing
Atmosphere
 Free of corrosive gas or conductive dust
