bonitron M3645 - Figure 3-1: M3645 Mounting Orientation

M3645
16
Figure 3-1: M3645 Mounting Orientation
Figure 3-1A
Figure 3-1D
HORIZONTAL SURFACE
UP
UP
BONITRON
Figure 3-1B
Figure 3-1E
UP
HANGING UNDERSIDE
Fig B
UP
BONITRON
Figure 3-1C
UP
PARALLEL TO FLOOR
BONITRON BONITRON
