User’s Manual
41
6. ENGINEERING DATA
6.1. RATINGS CHARTS
Table 6-1: Ratings and Specifications – 230 - 240VAC
MODEL
NUMBERS
CHASSIS
STYLE
DC REGEN CURRENT
POWER
MAX CONT.
WATT LOSS
CONT.
PEAK
CONT.
PEAK
M3645-L030
M10
30A
45A
14.4HP
21.6HP
180W
M3645-L050
M11
50A
75A
24.0HP
36.0HP
265W
M3645-L100
M12
100A
150A
48.0HP
72.0HP
470W
M3645-L300T
M15
300A
375A
144.0HP
180.0HP
2980W
Table 6-2: Ratings and Specifications – 380 - 415VAC
MODEL
NUMBERS
CHASSIS
STYLE
DC REGEN CURRENT
POWER
MAX CONT.
WATT LOSS
CONT.
PEAK
CONT.
PEAK
M3645-E030
M10
30A
45A
25.0HP
37.5HP
180W
M3645-E050
M11
50A
75A
41.7HP
62.6HP
265W
M3645-E100
M12
100A
150A
83.4HP
125.2HP
470W
M3645-E300T
M15
300A
375A
250.0HP
312.5HP
2980W
Table 6-3: Ratings and Specifications – 460 - 480VAC
MODEL
NUMBERS
CHASSIS
STYLE
DC REGEN CURRENT
POWER
MAX CONT.
WATT LOSS
CONT.
PEAK
CONT.
PEAK
M3645-H030
M10
30A
45A
28.8HP
43.2HP
180W
M3645-H050
M11
50A
75A
48.0HP
72.0HP
265W
M3645-H100
M12
100A
150A
96.0HP
144.0HP
470W
M3645-H300T
M15
300A
375A
288.0HP
360.0HP
2980W
Table 6-4: Ratings and Specifications – 575 - 600VAC
MODEL
NUMBERS
CHASSIS
STYLE
DC REGEN CURRENT
POWER
MAX CONT.
WATT LOSS
CONT.
PEAK.
CONT.
PEAK
M3645-C030
M10
30A
45A
36.0HP
54.0HP
180W
M3645-C050
M11
50A
75A
60.0HP
90.0HP
265W
M3645-C100
M12
100A
150A
120.0HP
180.0HP
470W
M3645-C300T
M15
300A
375A
360.0HP
450.0HP
2980W
A NOTE ON HP RATINGS
Modules are able to regenerate continuous power indefinitely. Modules can
regenerate peak power for at least 60 seconds.
Each unit’s regen current and power specifications must be derated by 2% per degree
Celsius ambient above 40°C.
