3.3.2. M3645-X300R LINE REACTOR MOUNTING
The installation of the M3645-x300R line reactor should be chosen with several
considerations in mind:
 The M3645-x300R line reactor is only required when using the 300A rated
M3645 in the M15 chassis.
 When mounting the line reactor in an enclosure, power dissipation should be
taken into account. Refer to Section 6.3 Watt Loss for details.
 The unit requires a minimum clearance of two inches (2”) in all directions around
it when not mounted near a heat source. Heat sources may increase necessary
clearances.
 Unit should not be exposed to falling debris or condensation.
 The unit can be mounted in any orientation.
Once the installation site has been selected as outlined above, the unit should be
mounted in place. See Section 6.6 for dimensional drawings.
3.3.3. KIT 3645DD, EXTERNAL DISPLAY MOUNTING
The KIT 3645DD external display is comprised of the display board assembly (ASM
3645D3) and a 12 foot long cable (CBL 3660DD4-DI12). The installation should be
chosen with several considerations in mind:
 The external display requires a cutout from the front panel. See Figure 6-6 for the
dimensional requirements for the cutout.
 The display will attach to the front of the panel. The display is secured to the
panel with a screw in each corner.
 The unit requires a minimum clearance of one (1) inch in all directions around it.
 The unit should not be exposed to falling debris or condensation.
 The 12 foot cable provided with the display must be attached to TB5 on the
control board of the M3645 and to TB3 on the ASM 3645D3 on the rear of the
display. See Figure 3-12.
Once the installation site has been selected as outlined above, the unit should be
mounted in place. See Section 6.6 for dimensional drawings.
NOTE: The KIT 3645DD is only compatible with “L” versions of the M3645 line regen.
Only a single display can be used for each line regen. The line regen is unable to
power more than a single display.
3.4. WIRING AND CUSTOMER CONNECTIONS
Be sure to review all pertinent AC drive and system documentation as well as the
information listed below before proceeding. Connection points and terminal numbers
of the AC drive will be found in the documentation provided with those units. See
Tables 3-1 thru 3-6 and Figures 3-2 thru 3-8 for connection details.
3.4.1. POWER WIRING
CAUTION!
Only qualified electricians should perform and maintain the interconnection
wiring of this product. All wiring should be in accordance with local codes.
DANGER!
Do NOT daisy chain the AC, DC, or ground connections between multiple
regen units. Each regen should have separate power and ground
connections.
