Монтаж и пуск INGENIO COMPACT ИБП 10÷20 кВА
Installation and start-up of INGENIO COMPACT 10÷20 kVA
OMS90050 РЕД. / REV.A
59
Details of the electrical connections
Power (kVA) 10 20
Input fuses [A]
Rectifier / Bypass 25 40
Phase conductor cross sect. [mm
2
]
Rectifier / Bypass 4x (1x6) 4x (1x10)
Output 4x (1x6) 4x (1x10)
Battery
3x (1x10)
3x (1x16)
Neutral conductor cross section
Linear load
Same as the phase
conductor
NON-linear load
x phase
conductor cross
section
Earth conductor cross sect. [mm
2
]
4 6
Power connections
Type Screw terminals
Conductor max. cross section [mm
2
] 10 16
Max. number of conductors 1
Tightening torque [Nm] 4 ÷ 4,5 4 ÷ 4,5
The data detailed in the table above are indicative only. The cables have been designed
according to the standard CEI-UNEL35024/1, using the following data:
use of single-pole copper cables with PVC insulation sheath
maximum temperature of the conductor equal to 70° C
ambient temperature equal to 40° C
maximum length of the cables equal to 30 m (voltage drop < 0,5%)
cables laid in cavities of structures or solid bottom cable trays
The given cross sections do not take into account the overload currents allowed by each line,
which are detailed in the product Technical Specification.
The UPS manufacturer is not responsible for the correct sizing of the device supply and output
lines, for which the plant conditions and operating temperatures, which are specific of each
electrical installation, must be taken into account.
Rated current (at full load and battery recharging)
Power (kVA) 10 20
Rectifier input [A]
(1)
18 36
Bypass input / Output [A]
(1) (2)
15 29
Battery [A] 33 66
(1)
Values referred to 400Vac rated voltage
(2)
For the overload values refer to the Technical Specification
