Borri INGENIO COMPACT - Battery Connection and Positioning

Монтаж и пуск INGENIO COMPACT ИБП 10÷20 кВА
Installation and start-up of INGENIO COMPACT 10÷20 kVA
OMS90050 РЕД. / REV.A 63
Internal batteries
The UPS can have internal batteries.
 Servicing of batteries should performed by qualified personnel only.
 Replace the batteries with the same number of block and capacity.
 Replace only with original type.
 CAUTION: do not dispose of batteries in fire. The battery may explode.
 CAUTION: do not open or mutilate batteries. Released electrolyte is harmful to
the skin and eyes. It may be toxic.
 CAUTION: do not dump the exhausted batteries in the environment.
4.4.1 Battery connection and positioning
Battery voltage
After the battery installation, before closing the fuses or the external isolator,
check the correct polarity of the battery voltage.
Picture 7 – Internal battery connection
