Borri INGENIO COMPACT - Preliminary Checks; Start-up Procedure

Монтаж и пуск INGENIO COMPACT ИБП 10÷20 кВА
Installation and start-up of INGENIO COMPACT 10÷20 kVA
68 OMS90050 РЕД. / REV. A
5.1 PRELIMINARY CHECKS
Before starting up the unit, make sure that:
 all installation and electric connection works have been performed professionally;
 all power and control cables have been properly and tightly connected to the relevant
terminal boards;
 the ground cable is properly connected;
 the battery polarity is correct and the voltage is within the operating values;
 the phase rotation of the line is correct and the voltage is within tolerance with the
operating values.
 the emergency power off “EPO” push-button, if installed, is not pressed (if not, press it
back to the rest position).
5.2 START-UP PROCEDURE
EPO push-button and phase rotation
Before switching the UPS on, make sure that:
1) the emergency power off “EPO” push-button, if installed, is not pressed. If not,
press it back to the rest position;
2) the input and output phase rotation is correct.
Battery isolators
Do not close the battery fuse (internal battery) or the external battery isolator BCB
before it’s required by the front panel. Serious damages to the UPS internal parts
and/or to the battery may occur.
Wiring of the auxiliary contacts
Carry out a proper electrical installation by wiring the auxiliary contacts of the external
manual bypass, output and battery isolators to the dedicated terminals on board the
UPS. This will allow the control logic to acquire the status of the switches and guide
the operator during the start-up and manual bypass procedures.
5.2.1 NORMAL START-UP
1) Open the front door the access the switches / isolators.
2) Close the power supply fuse, placed in the upper part of the UPS, and wait for the
display to start.
3) Close the INPUT switch.
