Монтаж и пуск INGENIO COMPACT ИБП 10÷20 кВА
Installation and start-up of INGENIO COMPACT 10÷20 kVA
66 OMS90050 РЕД. / REV. A
Output Function
OUT-1 General alarm
OUT-2 Load on inverter
OUT-3 Load on bypass
IN Configurable
The jumpers J1÷J3 are used to set the position of the output contacts, normally open or
normally closed.
Relay output characteristics:
250 Vac voltage 2 A current
30 Vdc voltage 2 A current resistive load
The definition for each contact can be modified, please contact the local authorized service
agent to change the setting.
