7.15 Register (0x21) Pressure LSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
press_15_8
press_15_8:(bit offset: 0) Pressure LSB Press_Data arithmetic representation: (signed, 24, 6) [Pa]
7.16 Register (0x22) Pressure MSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
press_23_16
press_23_16:(bit offset: 0) Pressure MSB Press_Data arithmetic representation: (signed, 24, 6) [Pa]
7.17 Register (0x23) Reserved
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_reg1
reserved_reg1:(bit offset: 0) reserved (read returns always 0x00)
7.18 Register (0x24) Reserved
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_reg2
reserved_reg2:(bit offset: 0) reserved (read returns always 0x00)
7.19 Register (0x25) Reserved
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_reg3
reserved_reg3:(bit offset: 0) reserved (read returns always 0x00)
