7.10 Register (0x1C) Reserved
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_reg0
 reserved_reg0:(bit offset: 0) reserved (read returns always 0x00)
7.11 Register (0x1D) Temperature XLSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
temp_7_0
 emp_7_0:(bit offset: 0) Temperature XLSB Temp_Data arithmetic representation: (signed, 24, 16) [degC]
7.12 Register (0x1E) Temperature LSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
temp_15_8
 temp_15_8:(bit offset: 0) Temperature LSB Temp_Data arithmetic representation: (signed, 24, 16) [degC]
7.13 Register (0x1F) Temperature MSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
temp_23_16
 temp_23_16:(bit offset: 0) Temperature MSB Temp_Data arithmetic representation: (signed, 24, 16) [degC]
7.14 Register (0x20) Pressure XLSB
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
1
1
1
1
1
1
1
Content
press_7_0
 press_7_0:(bit offset: 0) Pressure XLSB Press_Data arithmetic representation: (signed, 24, 6) [Pa]]
