7.8 Register (0x17) Number of frames in FIFO
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R
R
R
R
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_7_6
fifo_count
 fifo_count:(bit offset: 0) Number of frames in FIFO
 reserved_7_6:(bit offset: 6) reserved
7.9 Register (0x18) FIFO selection configuration
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_7_5
fifo_dec_sel
fifo_frame_sel
 fifo_frame_sel:(bit offset: 0) FIFO frame data source selection
Value
Description
0b00 (0x0)
FIFO not enabled
0b01 (0x1)
Temperature data
0b10 (0x2)
Pressure data
0b11 (0x3)
Pressure and temperature data
 fifo_dec_sel:(bit offset: 2) FIFO decimation selection
 reserved_7_5:(bit offset: 5) reserved
