7.6 Register (0x15) INT source selection
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R
R
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_7_4
oor_p_en
fifo_th...
fifo_fu...
drdy_da...
drdy_data_reg_en:(bit offset: 0) Data Ready
fifo_full_en:(bit offset: 1) FIFO Full (FIFO_FULL)
fifo_ths_en:(bit offset: 2) FIFO Threshold/Watermark (FIFO_THS)
oor_p_en:(bit offset: 3) Pressure data out-of-range (OOR_P)
reserved_7_4:(bit offset: 4) reserved
0x00: Disable INT. Except the POR and Software_reset completion
7.7 Register (0x16) FIFO configuration
Bit
7
6
5
4
3
2
1
0
Read/Write
R
R
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
reserved_7_6
fifo_mode
fifo_threshold
 fifo_threshold:(bit offset: 0):
Values Description
0x0 Disable the FIFO threshold
0x1F Set the FIFO threshold to 31 frames
 fifo_mode:(bit offset: 5) FIFO Mode CTRL:
Value
Description
0b0 (0x0)
Stream-to-FIFO Mode
0b1 (0x1)
STOP-on-FULL Mode
 reserved_7_6:(bit offset: 6) reserved
