SoftwareDescription
FlexibleAutomation
5−15
Example
;Comparison of allocation lists desired
L W K0002H,B ;Load K0002H to register B
T W B,S0
;Copy data module to DB
L W K0004H,B
T W B,S0
Bit15 21034567891011121314
S0
XXXXXXXXXXXXX X11
X:arbitrary
Fig.5−10Control WordS0
Cycle TimeS2 Main software watch dog (factor * 10 ms)
Default approx. 1.6 sec
Example
;Factor definition in OM7
L W K120D,B ;Watchdog = 1.2 sec
T W B,S2
Entries which exceed the value of the hardware watchdog (approx.
1.6sec) have no effect.
Time Base 1S4 Time base for time−controlled program execution in OM5
(factor * 10 ms, 10 min max.)
Default inactive (0)
Example
;Factor definition in OM7
L W K6000D,B ;Time base = 1 min
T W B,S4
