SoftwareDescription
FlexibleAutomation
5−16
Time Base 2S6 Time base for time−controlled program execution in OM6
(factor * 10 ms, 10 min max.)
Default inactive (0)
Example
;Factor definition in OM7
L W K600D,B ;Time base = 6 s
T W B,S6
Data ModuleS8 Length and number of the data module to be copied to DB (Data Buffer)
Default Length and number = 0
Example
;Definition of module number and module length
L W K01FFH,B ;DM No. = 1, Length = 256 words
T W B,S8
Bit 15 078
S8 ModuleNumber ModuleLength
Fig.5−11Data ModuleS8
Marker RemanencyS10 Limiting (byte) address for marker remanency
Default Byte 0−127 non−remanent (M0−M127)
Byte 128−255 remanent (M128−M255)
Example
;Definition of the marker remanency limit
L W K101D,B ;M101 1st marker remanent byte
T W B,S10
