SystemModules
FlexibleAutomation
4−44
4.4 Output Modules
Allspecificationsforoutputmodulesarereferencedtooperationwithafanunit.
Caution
4.4.1 Digital Output Modules
Function The digital output modules convert the internal signal levels to the exter
nal process signals.
Configuration 8−channel, 16−channel, and 32−channel output modules are avail
able. The output circuits are electrically isolated from the internal logic
circuits through optocouplers and are overload protected by fuse links or
electronic circuit breakers. Each output has its own LED for indication of
the signal state.
LED off −−> Logic 0"
LED on −−> Logic 1"
Connection All transducers are connected by plug−in terminals. This allows the re
placement of modules without removing the wire connections.
Cable Cross−section:1.5mm@ max.
Current Capacity of 1 Terminal: 6 A max. per contact
Specifications The following table lists the specifications of output modules.
