SystemModules
FlexibleAutomation
4−43
Transducer Connection Two−wire connection
Four−wire connection with RTDs
Wiring Twisted pair, shielded
Max. Cable Length 200 m
Constant Current Source 2mA for RTD measurements
Power Supply 24VDC to DIN 19240
Current Consumption 150mA internal
300mA external
Slot The analog input module can be installed in slots 4 to 14 of the
GG300/301 Basic Units, in slots 4 to 8 of the GG300−K/301−K Basic
Units and in slots 1 to 14 of the expansion units.
.Note,
Analog input modules require the use of a fan unit in the card cage.
Ordering Information Order No.
Analog Input Module, 16 Input Channels 046088
