SystemModules
FlexibleAutomation
4−42
4.3.3 Analog Input Module, 16 Inputs
Function The function of the analog input module is to detect voltages and cur
rents and to measure temperatures by means of RTDs.
Analog input has its own control logic and performs data acquisition in a
cycle which is independent of the controller. The digitized data are stored
in a special memory from where they can be retrieved by the controller at
any time.
The analog input module is operated in the extended inputs/outputs (IO/
EO). It occupies one input and output word in the extended inputs/out
puts.
A detailed description of the analog input module is given in Technical
Description" P. − N o . 3779.
Specifications
Measuring Ranges and Voltage Measuring Range: 50mV to 10V
Maximum Input Rating Max. Overvoltage:Supply Volt. 20V
Current Measuring Range:1mA to 20 mA
Max. Overcurrent:70mA
Temperature Measurement using RTDs (e.g. PT100)
50mV to 10V
Temperature Measuring Range
Total R for all RTDs:4.5 kW
Number of Inputs 16 differential inputs
8 differential inputs with RTDs
Maximum Number of Cards
per CL300 32
