Page 78 P/N: 4998152533-02 Copyright 2007 Bosch Security Systems, Inc. DS7200V2-UK Installer's Guide
PART IV: CONTROL PANEL PROGRAMMING
Options 1 for Zone Function Type 4 (24-Hour Tamper)
• Address: See Table 30
• Default: See Table 30
• Selections: 0, 2, 8, 10
The 24-hour Tamper zone function type uses the following parameter option chart.
Enter This Data Digit to Select Options
24-hour Tamper Input Options 0 1 2 3 4 5 6 7 8 9 10
11
12
13
14
15
No Options Selected
•
Reserved
Voice Verification
•
•
Reserved
No EOL Resistor Required
•
•
See the option descriptions for “Voice Verification” and “No EOL Resistor Required” in Options 1 for Zone Function Type 3
(24-Hour Control Input)
on page 77.
Options 1 for Zone Function Type 10 (Controlled Keyswitch)
• Address: See Table 30
• Default: 8 (Momentary, All On, Off from Any)
• Selections:
− 0 = Maintained, All On, Off from Any
− 1 = Maintained, All On, No Off
− 2 = Maintained, No On, Off from Any
− 4 = Maintained, Perimeter Only, Off from Any
− 5 = Maintained, Perimeter Only, No Off
− 6 = Maintained, No On, Off from Perimeter Only or Partial On Arming
− 8 = Momentary, All On, Off from Any
− 9 = Momentary, All On, No Off
− 10 = Momentary, No On, Off from Any
− 12 = Momentary, Perimeter Only, Off from Any
− 13 = Momentary, Perimeter Only, No Off
− 14 = Momentary, No On, Off from Perimeter Only or Partial On Arming
− 15 = Exit Terminator Button
• Momentary Keyswitch: To silence alarms (stop Alarm output), operate the keyswitch. If the area is armed, operating the
keyswitch to silence the alarm also disarms the area. If the area is disarmed, operating a momentary keyswitch to silence the
alarm does not arm the area.
• Maintained Keyswitch: To silence alarms (stop Alarm output) while the area is armed, turn the keyswitch to the disarmed
position. The control panel disarms the area and silences alarms. To silence alarms (stop Alarm output) while the area is
disarmed, turn the keyswitch to the armed position (the control panel does not arm) and then return to the disarmed position.
• Exit Terminator Button: When the Zone Functions Options 1 parameter (see “Options 1, Zone Function ##” in the
DS7200V2 Expert Programming Guide (P/N: 4998153891)) is set to 15, the input functions as an exit terminator button. This
zone function activates in the same manner as the momentary keyswitch. When Exit Delay is active, operating the exit
terminator button terminates Exit Delay and immediately arms the control panel. If Chime Mode is enabled and Exit Delay is
not active, pressing the exit terminator button activates the chime tone and the button functions as a doorbell.
