Designation product ID
FAS-ASD-CLT Ceiling lead-through, white, ABS, 10 per set F.01U.029.725
FAS-ASD-AHC Aspiration hose (PE) for ceiling lead-through F.01U.029.727
FAS-ASD-DSB Detonation safety barrier for 25mm pipe system F.01U.029.716
FAS-ASD-WS Water separator with sintered metal filter and manual
drain valve, including mounting bracket and PG cable
glands for 25mm pipe system
F.01U.029.717
FAS-ASD-FL Large air filter box, for 25mm pipe system, inc. 1 filter
set and two PG29 screw connections
F.01U.029.714
FAS-ASD-RFL Replacement filter set for large air filter box F.01U.029.715
Notice!
Four 45° pipe elbows are required to install the FAS-ASD-WS water separator.
Air sampling opening components
Designation product ID
Marking tape for aspiration reducing film sheet AF-BR, 10 units. 4.998.143.413
Aspiration reducing film sheet 2.0mm AF-2.0, 10 units. 4.998.143.416
Aspiration reducing film sheet 2.5mm AF-2.5, 10 units. 4.998.143.417
Aspiration reducing film sheet 3.0mm AF-3.0, 10 units. 4.998.143.418
Aspiration reducing film sheet 3.2mm AF-3.2, 10 units. 4.998.143.419
Aspiration reducing film sheet 3.4mm AF-3.4, 10 units. 4.998.143.420
Aspiration reducing film sheet 3.6mm AF-3.6, 10 units. 4.998.143.422
Aspiration reducing film sheet 3.8mm AF-3.8, 10 units. 4.998.143.423
Aspiration reducing film sheet 4.0mm AF-4.0, 10 units. 4.998.143.424
Aspiration reducing film sheet 4.2mm AF-4.2, 10 units. 4.998.143.425
Aspiration reducing film sheet 4.4mm AF-4.4, 10 units. 4.998.143.426
Aspiration reducing film sheet 4.6mm AF-4.6, 10 units. 4.998.143.427
Aspiration reducing film sheet 5.0mm AF-5.0, 10 units. 4.998.143.428
Aspiration reducing film sheet 5.2mm AF-5.2, 10 units. 4.998.143.429
Aspiration reducing film sheet 5.6mm AF-5.6, 10 units. 4.998.143.430
Aspiration reducing film sheet 6.0mm AF-6.0, 10 units. 4.998.143.431
Aspiration reducing film sheet 6.8mm AF-6.8, 10 units. 4.998.143.432
Aspiration reducing film sheet 7.0mm AF-7.0, 10 units. 4.998.143.433
