Bosch FCS-320-TP2 - Technical Data; FCS-320 Series Aspirating Smoke Detectors

28 en | Technical Specifications Aspirating Smoke Detector
2018.04 | 2.0 | F.01U.130.926 Operation Guide Bosch Sicherheitssysteme GmbH
Notice!
Plastic clips for deep-freeze facilities and blowing-out systems are sold separately.
3.8 Technical data
3.8.1 FCS-320 Series Aspirating Smoke Detectors
Electrical
Power supply 15VDC to 33VDC
auxiliary power supply 14VDC to 30VDC
Current consumption from auxiliary power supply
(at24V)
FCS-320‑TP1
FCS-320-TT1
FCS-320‑TP2
FCS-320‑TT2
– Starting current, fan voltage 6.9V 300mA 330mA
– Starting current, fan voltage 9V 300mA 330mA
– On standby, fan voltage 6.9V 200mA 230mA
– On standby, fan voltage 9V 260mA 310mA
– On alarm, fan voltage 6.9V 230mA 290mA
– On alarm, fan voltage 9V 290mA 370mA
Mechanics
Displays on the device FCS-320-TP1/FCS-320-TP2
– Operation Green LED
– Fault Yellow LED
– Alarm 1 red LED/2 red LEDs
Displays on the device FCS-320-TT1/FCS-320-TT2
– Operation Green LED
– Fault Yellow LEDs
– Level display 1 x / 2 x smoke level display, each
with 10segments (1–10)
– Alarm 1 x 3 / 2 x 3 red LEDs for info alarm,
pre-alarm and main alarm
Conical duct connections for Ø25mm
– Aspiration pipe 1 pipe/2 pipes
– Air-return pipe 1 pipe
Cable bushings 5 x M 20 and 2 x M 25
Dimensions (H x W x D) 292 x 200 x 113mm
Weight Approx. 1.5kg
