In normal operation, the steam and gas mixtures flow in any direction through the safety
barrier. An ignition of the mixture in the upstream aspirating smoke detector will cause the
developing detonation to be arrested. Ignition is prevented by the flame filter. Combustion of
the mixture in the flame filters may cause a rebound of the detonation front. To prevent this, a
minimum pipe length of 1.0m between the installation point of the detonation safety barrier
and a possible ignition source (aspirating smoke detector) must be maintained. Permanent
fire prevention is thus achieved indirectly.
!
Caution!
The connecting pipe between the aspirating smoke detector and the detonation safety barrier
must be made of metal. During installation, care must be taken to ensure that the threaded
connections are bolted together gas-tight using synthesol or sealing tape.
3.7 Scope of Delivery: Smoke Aspiration System
Basic devices and accessories
Designation product ID
FCS-320-TP1 Standard unit F.01U.141.197
FCS-320-TP2 Standard unit F.01U.141.198
DM-TP-50(80) Detector module 4.998.143.394
DM-TP-10(25) Detector module 4.998.143.395
DM-TP-01(05) Detector module 4.998.143.396
TITANUS MT-1 MT-1 device mounting for aspirating smoke detector 4.998.143.410
FAS-ASD-DIAG DIAG diagnostic software including connection cable, for
USB port
F.01U.033.505
FCA‑320‑Reset Reset board F.01U.141.199
FCS-320-IK Installation kit F.01U.141.201
RAS Test Pipe Test pipe 4.998.148.848
RAS Test
Adapter
Test Adapter 4.998.148.849
Pipe system components
Designation product ID
FAS-ASD-PHF16 Polywell aspiration hose, flexible, black, halogen-free F.01U.029.719
FAS-ASD-
TRPG16
Ring nut with PG16 internal thread, 5per set F.01U.029.721
FAS-ASD-CSL Quick-lock coupling, straight, PG16 internal thread F.01U.029.720
FAS-ASD-3WT Three-way tap, incl. fittings, for 25mm pipe system F.01U.029.718
FAS-ASD-F Flange for ventilation duct F.01U.029.722
FAS-ASD-AR Aspiration reduction, with 10mm bore for attaching an
aspiration reducing film sheet, 10 per set
F.01U.029.724
