Bosch FCS-320-TP2 - Pipe System; Smoke Aspiration System Components

Aspirating Smoke Detector Technical Specifications | en 29
Bosch Sicherheitssysteme GmbH Operation Guide 2018.04 | 2.0 | F.01U.130.926
Housing material Plastic (ABS)
Housing color Papyrus white (RAL 9018)
Environmental conditions
Protection category as per EN 60529 IP 20
Permissible temperature range of aspirating smoke
detector
-20°C to +60°C
Permissible relative humidity (non-condensing) 10 to 95%
Special features
sound power level 45 dB(A)
Max. response sensitivity (max. light obscuration)
– DM‑TP‑50(80) Detector Module 0.5%/m (0.8%/m) *
– DM‑TP‑10(25) Detector Module 0.1%/m (0.25%/m) *
– DM‑TP‑01(05) Detector Module 0.015%/m (0.05%/m) *
Life cycle of the fan (12V) 43,000 hrs at 24°C
* The sensitivity value is based on measurements with standard test fires (old value in
brackets).
3.8.2 Pipe System
FCS-320-TP1
FCS-320-TT1
FCS-320-TP2
FCS-320-TT2
Maximum pipe length 300m 2 x 280m
Maximum number of air sampling openings 32 2 x 32
Maximum size of monitoring area 2880m
2
5760m
2
Permissible temperature range
– PVC pipe system 0°C to +60°C
– ABS pipe system -40°C to +80°C
3.8.3 Smoke Aspiration System Components
Water separator (FAS‑ASD‑WS)
Features For use in areas with very high humidity
Plastic housing with manual drain valve
Sintered metal filter
PG cable glands for 25mm pipe system
Incl. assembly bracket
Dimensions (H x W x D) 210 x 170 x 90mm
Weight Approx. 1.4kg
