66 en | Planning Aspirating Smoke Detector
2018.04 | 2.0 | F.01U.130.926 Operation Guide Bosch Sicherheitssysteme GmbH
D - - a 7.0 7.0 4.6 3.4 3.0 2.5 2.5 2.5
E - - - a 7.0 7.0 4.0 3.2 3.4 2.5 2.5
F - - - - a 7.0 6.8 3.6 3.4 2.5 2.5
G - - - - - a 7.0 6.8 3.6 3.2 2.5
H - - - - - - a 7.0 6.0 3.6 3.4
I - - - - - - - a 7.0 6.0 3.6
J - - - - - - - - a 7.0 5.6
K - - - - - - - - - a 7.0
L - - - - - - - - - - a
M - - - - - - - - - -
N - - - - - - - - - -
O - - - - - - - - - -
P - - - - - - - - - -
Q - - - - - - - - - -
R - - - - - - - - - -
S - - - - - - - - - -
T - - - - - - - - - -
U - - - - - - - - - -
V
a = Acceleration openings = 7.0 mm
Number of apertures
36 39 42 45 48 51 54 57 60 63
Sampling aperture type Ax-x.x
A 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
B 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
C 2.5 2.5 2.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0
D 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0
E 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0
F 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0
G 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0
H 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
I 3.4 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
J 3.6 3.0 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
K 5.0 3.5 3.0 2.5 2.5 2.5 2.5 2.5 2.5 2.5
