J - - - - - - - - a 7.0 5.6 3.6 3.0
K - - - - - - - - - a 7.0 5.0 3.6
L - - - - - - - - - - a 7.0 4.6
M - - - - - - - - - - a 7.0
N - - - - - - - - - - - - a
O - - - - - - - - - - - - -
P - - - - - - - - - - - - -
Q - - - - - - - - - - - - -
R - - - - - - - - - - - - -
S - - - - - - - - - - - - -
T - - - - - - - - - - - - -
U - - - - - - - - - - - - -
V - - - - - - - - - - - - -
W - - - - - - - - - - - - -
X - - - - - - - - - - - - -
Y - - - - - - - - - - - - -
Z - - - - - - - - - - - - -
a = Acceleration openings = 7.0 mm
Number of apertures
56 60 64 68 72 76 80 84 88 92 96 100
Sampling aperture type Ax-x.x
A 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
B 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
C 2.5 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
D 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0 2.0 2.0
E 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0 2.0 2.0
F 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0 2.0
G 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0 2.0
H 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0
I 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0 2.0
J 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0
K 3.0 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0 2.0
L 3.6 3.0 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0
M 4.0 3.6 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.0 2.0
